3. Description
3
Service
manual
487 05 40 31
3.4
Operating panel
There are different types of operating panels.
On the dryer operating panel the buttons might not have any symbols in which case they
are only usable when the dryer is in service mode.
Fig. 1 In service mode the 4 buttons are used for changing the parameters.
Selected temperature
Light emitting diode is lit at the selected temperature or show the default-temperature
setting.
Default temperature can be set in Group A in parameter A 05.
487 09 10 01.00
SELECTA CO N TRO L
Down
Up
EnterReturn
1
High
No heat
Medium
Low
