Electrolux T4250 - Group A: Customized User Panel

487 05 40 31
4.25
4. Programmes
4
Service
manual
Group A - Setting programs
Adjustable parameters
Factory
setting
Para-
meter /
group
Comments
A 01
Standby value 000 - 0999 1 Value shown when dryer is free
A 02
Standby value blinks 00/01 1 01/00 01 = Value blinks when dryer is free
A 03 Final blinks 00/01 1 01/00 01 = Final symbol blinks
A 04 Show temperature 00/01 1 01/00 01 = Temperature is displayed when temp. key
is activated.
A 05 Default temperatur setting 0 - 5 1 0 No default
1 Max
2 Medium
3 Low
4 Now heat
5 Last temperature
A 06 Min. minutes between pendling 255 sec. 1 Second
120 Electric, Steam
20 Gas heated dryer
Electric heated dryer T4250/T4350
Electric heated dryer T4190
Electric heated dryer T4300
Designation Range Step
Customized user panel
