12. Error codes
12
Service
manual
E 15 - Air pressure switch or vacuum switch
Error description
The air pressure switch or the vacuum switch does not shut within 12 seconds after the
fan has started.
Error analysis
Check the motor’s
connection and phase
order.
NO
YES
Go to step 3.
2. Does the fan motor
rotate in the correct
direction?
(Section 11)
Resetting
Resetting is done by opening/closeing the door to the dryer and pressing the start button
NO
YES
YES
Replace PCB
3. Is the measuring
over 100V AC
between P2-5 and
P2-2 within 12
seconds when dryer
is not operating.
NO
See check list.
Correct airflow problem
as appropriate.
1 Is the
underpressure in the
drum compartment
below 90Pa.
(Section 46)
Go to step 2.
Replace the air pressure
switch.
