Installation
25
Gas group Injector size
Ø mm (1)
Air reducing
plate (g. 5)
Inlet pres-
sure (mbar)
Injector
pressure
(mbar)
Label no.
(g. 10 )
I2H, I2E(LL) 3.8 Ø38 20 10.5 DEFAULT
I2E+ 3.3 Ø38 20/25 20/25 487266723
I2L (LL) 3.8 Ø38 20/25 15, 2 487266723
I3B/P, I3+ 2.3 NONE 30, 28/37 30, 28/37 487266721
I3B/P (37) 2.1 NONE 37 37 487266722
I3B/P (50) 2.3 NONE 50 30 487266722
Gas installation - table of pressure and adjustment
This gas appliance has been build to run on natural gas group I2H and I2E(LL), commonly
identified by GNH.
The data label shows the injector size and the injector pressure and the countries that use this
gas quality: DK, NO, SE, FI, CH, CZ, EE, LT, SL, TR, BG, RO, GB, ES, GR, IE, IT, PT, AT, LV,
HU, IS, SK, DE, PL, LU and non-European countries.
Before connecting the appliance please make sure that the supplied gas type is correct.
Following gas conversions are possible:
1. Appliances to be installed to run on GNH or GNL in FR, BE: I2E+
2. Appliances to be installed in NL, parts of DE and Non-European contries: I2L.
3. Appliances to be installed to run on LPG in: DK, NO, SE, FI, EE, LT, SL, TR, DE, NL,
CH, CZ, HU, GR, MT, CY, LV, SK, LU, BG and Non-European contries: I3B/P .
4. Appliances to be installed to run on LPG in: GB, ES, GR, IE, IT, PT, CH, CZ, BE, FR,
CY, EE, LV, LT, LU, RO: I3+ .
5. Appliances to be installed to run on LPG in: AT: I3B/P (50 mbar) inlet pressure.
6. Appliances to be installed to run on LPG in: PL: I3B/P (36 mbar) inlet pressure.
Fig. 1 - T4290 only
Gas group Injector size
Ø mm (1)
Air reducing
plate (g. 7)
Inlet pres-
sure (mbar)
Injector
pressure
(mbar)
Label no.
(g 10)
I2H, I2E(LL) 5.6 Ø40 20 8 DEFAULT
I2E+ 4.7 Ø40 20/25 20/25 487266733
I2L (LL) 6.2 Ø40 20,25 8 487266733
I3B/P, I3+ 3.2 Ø40 30, 28/37 30, 28/37 487266731
I3B/P (37) 3.05 Ø40 37 37 487266732
I3B/P (50) 3.2 Ø40 50 30 487266732
Fig. 2 - T4530 only
