Electrolux T4530 - Page 26

Installation
26
Gas group Injector size
Ø mm (1)
Air reducing
plate (g. 9)
Inlet pres-
sure (mbar)
Injector
pressure
(mbar)
Label no.
(g. 10)
I2H, I2E(LL) 6.5 Ø32 20 9.5 DEFAULT
I2E+ 5.4 Ø32 20/25 20/25 487266738
I2L (LL) 6.5 Ø32 20,25 14 487266738
I3B/P, I3+ 3.8 Ø40 30, 28/37 30, 28/37 487266736
I3B/P (37) 3.5 Ø40 37 37 487266737
I3B/P (50) 3.8 Ø40 50 30 487266737
Fig. 3 - T4650 only
