Installation
36
Steam
Electric
Electric installation - T4290
Fuse sizes, effects and voltages
Voltage
Heat effect
kW
Motor effect
kW
Max.
effect
kW
Fuse
Gas
230-240V 3AC 50/60Hz w/reversing 21 kW 1.5 kW 1.5 kW 10A
230-240V 3AC 50/60Hz wo/reversing 21 kW 1.0 kW 1.0 kW 10A
230-240V 1AC 50/60Hz 21 kW 1.5 kW 1.5 kW 10A
400-480V 3AC 60HZ w/reversing 21 kW 1.5 kW 1.5 kW 10A
400-480V 3AC 60HZ wo/reversing 21 kW 1.0 kW 1.0 kW 10A
400-415V 3AC 50Hz w/reversing 21 kW 1.5 kW 1.5 kW 10A
400-415V 3AC 50Hz wo/reversing 21 kW 1.0 kW 1.0 kW 10A
230-240V 3AC 50/60Hz w/reversing 1.5 kW 1.5 kW 10A
230-240V 3AC 50/60Hz wo/reversing 1.0 kW 1.0 kW 10A
230-240V 1AC 50/60Hz 1.5 kW 1.5 kW 10A
400-480V 3AC 60HZ w/reversing 1.5 kW 1.5 kW 10A
400-480V 3AC 60HZ wo/reversing 1.0 kW 1.0 kW 10A
400-415V 3AC 50Hz w/reversing 1.5 kW 1.5 kW 10A
400-415V 3AC 50Hz wo/reversing 1.0 kW 1.0 kW 10A
230-240V 3AC 50/60Hz 13,5 kW 1.5 kW 15.0 kW 50A
400-415V 3AC 50/60Hz 13,5 kW 1.5 kW 15.0 kW 25A
440-480V 3AC 60 Hz 13,5 kW 1.5 kW 15.0 kW 20A
230-240V 3AC 50/60Hz 18 kW 1.5 kW 19.5 kW 50A
400-415V 3AC 50/60HZ 18 kW 1.5 kW 19.5 kW 35A
440-480V 3AC 60 Hz 18 kW 1.5 kW 19.5 kW 25A
