Installation
37
230-240V 3AC 50/60 Hz 40 kW 1.5 kW 1.5 kW 10A
230-240V 1AC 50/60Hz 40 kW 1.5 KW 1.5 kW 10A
400-415V 3AC 50/60Hz 40 kW 1.5 kW 1.5 kW 10A
440-480V 3AC 60Hz 40 kW 1.5 kW 1.5 kW 10A
230-240V 3AC 50/60 Hz - 1.5 kW 1.5 kW 10A
230-240V 1AC 50/60Hz - 1.5 kW 1.5 kW 10A
400-415V 3AC 50/60Hz - 1.5 kW 1.5 kW 10A
440-480V 3AC 60Hz - 1.5 kW 1.5 kW 10A
230-240V 3AC 50/60Hz 24 kW 1.5 kW 25.5 kW 80A
400-415V 3AC 50/60Hz 24 kW 1.5 kW 25.5 kW 50A
440-480V 3AC 60Hz 24 kW 1.5 kW 25.5 kW 50A
230-240V 3AC 50/60Hz 30 kW 1.5 kW 31.5 kW 100A
400-415V 3AC 50/60Hz 30 kW 1.5 kW 31.5 kW 50A
440-480V 3AC 60Hz 30 kW 1.5 kW 31.5 kW 50A
Gas
Electric installation - T4530
Fuse sizes, effects and voltages
Voltage Heat effect
kW
Motor effect
kW
Max.
effect
kW
Fuse
Steam
Electric
