User manual
12.3 Cleaning the condenser
If the symbol Condenser flashes on the display, the condenser and its compartment must be cleaned.
To clean the condenser and its compartment:
1. Open the door.
2. Slide the release button on the bottom of the door to open the condenser door.
fig.X02233
3. Turn the two blockages to unlock the condenser cover.
fig.X02234
4. Lower the condenser cover.
fig.X02235
5. Catch the handle and pull the condenser out from the bottom compartment. Move condenser horizontally to do
not spill remaining water.
fig.X02236
6. Clean the condenser in vertical position over a basin or paddling. Rinse through with a hand shower.
fig.X02237
