Electrolux WP4 700H - Page 37

Installation manual
37
Barrier WPB4 1100H: Drawing 07100137
Washer extractor type 1100 (Diagram N° 07100136 and 07100137)
Units WP4 1100 WPB4 1100
Drum diameter mm / “ 1050 / 41.33” 1050 / 41.33”
Drum length
mm / “ 1256 / 49.45” 1256 / 49.45”
