Installation manual
41
Heating
Units WP4 1100 WPB4 1100
Installed heating power, electric heating
kW 72 72
Electric consumption for a standardized cycle, electric heating
kWh 25.3 25.3
Electric consumption for a standardized cycle, steam heating
kWh 2.4 2.4
Floor load Units WP4 1100 WPB4 1100
Max transmitted floor load daN 4450 4450
Max. pressure transmitted to floor
kPa 178 178
Compressed air
Units WP4 1100 WPB4 1100
Compressed air inlet
mm
6/8 6/8
Min./max. compress air pressure
bar 5.5/7 5.5/7
Consumption
l/h 50 50
7 Sound levels
The sound power level of the machine is determined by using ISO 3747:2012.
According to test code EN50571 : 2013 anex CC,the sound power level at extraction and during washing are accord-
ing to the table:
Airbone noise emitted by the machine (values established from measurements made on machine at points A,B,C,
and D)
Weighted sound
pressure level in
dB (A)
Washer 700 (Without insulation) Washer 900 (Without insulation) Washer 1100 (Without insulation)
Washing High spin
extraction
Washing High spin
extraction
Washing High spin
extraction
A 63.5 82.2 63.5 82 66 81.5
B 64 81.3 64.2 81 66 81.5
C 63 83.9 63.8 83 67 83
D 64 82.7 64.2 83 67 83
8 Working place lighting
The lighting should be designed so as to avoid eye strain for the operator ; it should be uniform without any glare,
and should be sufficient to detect any hazards.
The average lighting value on the working place recommended by the clothing industry for inspecting linen is 500 lux.
Whenever possible, the working place should be illuminated by daylight.
