Installation manual
18Note about the A.C. power
According to the EN 60204-1:1997 standard, the machine is provided for A.C. supplies corresponding to the ex-
tracted characteristics below :
4.3.2 A.C. supplies
Voltage:
Steady state voltage: from 0.9 to 1.1 of nominal voltage.
Frequency:
from 0.99 to 1.01 of nominal frequency continuously.
from 0.98 to 1.02 short time.
Harmonics:
Harmonic distortion not to exceed 10 % of the total r.m.s. voltage between live conductors for the sum of the second
through to the fifth harmonic. An additional 2 % of the total r.m.s. voltage between live conductors for the sum of the
sixth through to the 30th harmonic is permissible.
Voltage unbalance:
Neither the voltage of the negative sequence component nor the voltage of the zero sequence component in three-
phase supplies shall exceed 2 % of the positive sequence component.
Voltage interruption:
Supply interrupted or at zero voltage for not more than 3 ms at any random time in the supply cycle. There shall be
more than 1 second between successive interruptions.
Voltage dips:
Voltage dips shall not exceed 20 % of the peak voltage of the supply for more than one cycle. There shall be more
than 1 second between successive dips.
19Feeder cable sections
The feeder cable sections mentioned in our literature are given only as a guide.
To obtain a value perfectly suited to your own application and which takes account of the different correction factors
in respect of your plant, refer to the tables below.
Table 1 (in accordance with EN Standard 60204-1)
Values given for:
• Cable with copper conductors
• Cable with PVC insulation (for other insulants see Table 3)
• Ambient temperature 40°C max. (for others see Table 2)
• Three-phase cable under load without including starting currents
• BT / C/ E cable layout.
Maximum Admissible Current
Cable section Seated in Cable Duct or
Cable trough
Wall fixing Cable tray
B2 BC E
3 x 1.5 mm² 12.2 A 15.2 A 16.1 A
3 x 2.5 mm² 16.5 A 21 A 22 A
3 x 4mm² 23 A 28 A 30 A
3 x 6 mm² 29 A 36 A 37 A
3 x 10 mm² 40 A 50 A 52 A
3 x 16 mm² 53 A 66 A 70 A
3 x 25 mm² 67 A 84 A 88 A
3 x 35 mm² 83 A 104 A 114
3 x 50 mm²
-
123 A 123 A
3 x 70 mm²
-
155 A 155 A
Table 2 (correction factors for different ambient temperatures)
Ambient temperature Correction factor
30 °C 1.15
