7
CEL
D0842-4822-4822bis
C1 C2 C3 C4
230 VX9-CPU
UM
0107
71
11
Notice
Date
Page
01201138
INSTRUCTION
HANDBOOK
11. Machine
operation
Component locations
Fig.
7
UM Scale unit
CEL Load cells
Connectors
230 V Voltage feed
X9-CPU Communication with CPU board
C1-C4 Load cells
