D0671A
A
B
B
A
0107 3
6
Notice
Date
Page
01201138
INSTRUCTION
HANDBOOK
6. Handling
CAUTION
In order to avoid any bend-
ing of casings, you should
never climb and stand on
top of the machine.
4/ Lifting with a jack
Lifting in this case can only be done with a
jack (minimum capacity 500 daN) which can
bear the machine's weight.
Nota : in order to avoid the bending of the
sole, make sure to place the lifting jack at
each corner of the machine at point A or B.
