Electrolux WSB4250H - Page 60

0107 26
9
Notice
Date
Page
01201138
INSTRUCTION
HANDBOOK
9. Installation
Electrical liquid detergents' connection
If your machine have 1 I/O card, you have to use signal of detergent box.
Connectors card I/O no 1
Powder 1 IO1-X9-4
Powder 2 IO1-X9-5
Liquid 1 IO1-X14-1
Liquid 2 IO1-X14-2
Liquid 3 IO1-X14-3
Common IO1-X9-8
If your machine have 2 I/O cards, use signal 4 to 13.
Connectors card I/O no 2
Liquid 4 IO2-X9-3
Liquid 5 IO2-X9-4
Liquid 6 IO2-X9-5
Liquid 7 IO2-X9-6
Liquid 8 IO2-X9-7
Common IO2-X9-8
Liquid 9 IO2-X14-1
Liquid 10 IO2-X14-2
Liquid 11 IO2-X14-3
Liquid 12 IO2-X14-4
Common IO2-X14-5
Liquid 13 IO2-X8-1
Common IO2-X8-2
