9. Installation
Table 4
(B2, C and E correction factors for cable grouping)
B2 C E
Number Seated in Wall Fixing Cable
of cables Cable Duct or Cable Trough Tray
1 1.00 1.00 1.00
2 0.80 0.85 0.87
4 0.65 0.75 0.78
6 0.57 0.72 0.75
9 0.50 0.70 0.73
The total current included for using Table 1 should be the maximum rated current for the ma-
chine divided by the product of the different correction factors. Other correction factors may
also be applied ; consult the cable manufacturers.
Calculation : Example
- The machine has a rated current of 60 A.
- The ambient temperature is 45 °C ; Table 2 gives a correction factor of 0.91.
- Rubber cable insulant : Table 3 gives a correction factor of 0.92.
- The cable is fi xed directly to the wall (Column C), with 2 cables side by side. Table 4 gives a
correction factor of 0.85.
60 A
Total current : ----------------------- = 84 A
0.91 x 0.92 x 0.85
Taking Column C in Table 1 (wall fi xing), we obtain a minimum cable section of : 3 x 25 mm².
Machine Heating Supply Installed Rated Main Connection
type Voltage Power Intensity Switch Cable Fuse
Section
250 Gas/steam/T.F 380/415 V 3+E ~ 50/60 Hz 3.7 kW 8.5 A 3 x 16 A 4 x 2.5 mm² 3 x 16 A
250 Electric 380/415 V 3+E ~ 50/60 Hz 21.7 kW 33.5 A 3 x 40 A 4 x 6 mm² 3 x 40 A
350 Gas/Steam/T.F 380/415 V 3+E ~ 50/60 Hz 4.8 kW 11 A 3 x 16 A 4 x 2.5 mm² 3 x 16 A
350 Electric 380/415 V 3+E ~ 50/60 Hz 32 kW 50 A 3 x 63 A 4 x 16 mm² 3 x 63 A
500 Gas/Steam/T.F 380/415 V 3+E ~ 50/60 Hz 5.8 kW 12.5 A 3 x 16 A 4 x 2.5 mm² 3 x 16 A
500 Electric 380/415 V 3+E ~ 50/60 Hz 42 kW 64.5 A 3 x 80 A 4 x 25 mm² 3 x 80 A
650 Gas/Steam/T.F 380/415 V 3+E ~ 50/60 Hz 7.8 kW 16 A 3 x 20 A 4 x 2.5 mm² 3 x 20 A
650 Electric 380/415 V 3+E ~ 50/60 Hz 61.5 kW 94 A 3 x 100 A 4 x 35 mm² 3 x 100 A
