30
Max Displayed Range (Instrument Only):
Fuel Flow: 1999 Gals/Hr or 1999 br Gal/Hr or 1199 Lbs/Hr or 749 Ltr/Hr.
Fuel Remaining: 1999 Gals. or 811 br Gal. or 1999 Lbs. or 1999 Ltr.
Fuel Used: 1999 Gals. or 811 br Gal. or 1999 Lbs. or 1999 Ltr.
Time to Empty: 19 hours 59 minutes
Pressue: +/- 1999
RS-232/422 Input Ports:
Single Line Receive Method: RS-232C or RS-423
Dual Line Receive Method: RS-422 or RS-485 (with 120 ohm external resistor)
Protocol: 1 Start bit, 8 Data bits, 1 Stop bit.
Baud Rate: 4800 or 9600
Receive Format: Moving Map or NEMA.
RS-232/422 Output Port:
Transmit Method: RS-232C Single Line.
Protocol: 1 Start bit, 8 Data bits, 1 Stop bit.
Baud Rate: 9600 .
Transmit Format: King KLN88, Garmin, or UPS.
Fuel Flow Transducer, FT-60 (Red Cube):
Range: 0.6 to 70+ GPH
Linearity: 1% over an engines normal operating range.
K Factor: Approx. 68,000
Pressure Drop: 0.5 PSI at 28 GPH
2.0 PSI at 56 GPH
Working Press: 250 PSI
Min. Burst Press: 4,000 PSI
Temp. Range: -65'C to 125'C
Fuel Ports: 1/4" Female NPT
Fuel Flow Transducer, FT-90 (Gold Cube):
Range: 2 to 125+ GPH
K Factor: Approx. 33,800
Pressure Drop: 0.5 PSI at 63 GPH
2.0 PSI at 127 GPH
Working Press: 250 PSI
Min. Burst Press: 4,000 PSI
Temp. Range: -65'C to 125'C
Fuel Ports: 1/4" Female NPT
Fuel Pressure Transducer (PT-100GA):
Range: 0 to 100 PSI
Over Press: 300 PSI without damage.
Min. Burst Press: 500 PSI
Temp. Range: -40'C to 125'C
Material: 303 Stainless Steel
Press. Port: 1/4" Male NPT
Fuel Flow Transducer, FT-180 (Black Cube):
Range: 2 to 250+ GPH
K Factor: Approx. 22,700
Pressure Drop: 0.5 PSI at 88 GPH
2.0 PSI at 176 GPH
Working Press: 250 PSI
Min. Burst Press: 4,000 PSI
Temp. Range: -65 to 125'C
Fuel Ports: 1/4" Female NPT with #8
Female Flare Fitting
