Pet Immunity Guidelines (EL-4755PI)
It is expected that the EL-4755PI will eliminate false alarms caused by:
• Animals up to 36kg/80lbs
• Several small rodents
• Random flying birds.
The weight of the animal should only be used as a guide, other factors such as the length
and color of fur also affect the level of immunity.
For maximum pet immunity the following guidelines are recommended:
• Mount the center of the detector at a height of 2.0m.
• Do not aim the detector at stairways that can be climbed by an animal.
• Avoid a location where an animal can come within 1.8m (6') of the detector by climbing on furniture, boxes
or other objects.
Registration Procedure
The EL-4755/4755PI must identify itself to the iConnect
Control System as follows
1. Set the system to registration mode.
• Go to the main menu and select [9]>[1]>[1] (Programming > Devices > Zones)
• Select a zone and press '
√ʹ
2. Unscrew the casing back
3. Insert the supplied batteries into their battery holders. The detector will send a transmission, which if successfully
received by the system will generate a confirmation sound. If no confirmation sound is heard, send another
transmission by pressing and releasing the tamper switch of the device.
4. After the detector is successfully registered the display shows: Save? Press '
√ʹ to confirm and continue entering
other parameters for the chosen device.
To delete a PIR detector from the system refer to the Quick Installer manual.
Parameter Setting Procedure
As a 2-Way detector, the EL-4755/4755PI parameters can be modified only from the iConnect
Control System.
Go to the main menu and select [9]>[1]>[1]>[11] (Programming > Devices > Zones > Sensor Par) and define the parameters
according to the following table:
Table B- 1: Parameter Settings (EL-4755/EL-4755PI)
Sensor Par. Parameter
L E D ENABLED/DISABLED
PULSE 1, 2 – The pulse counter determines the amount of beams that need to
be crossed before the sensor will produce an alarm, with 1 being more
sensitive:
ALARM DELAY 1–20 minutes (3) – The delay between reporting detections to the main
unit
CAMERA RESOLUTION VGA (640X480), QVGA (320X240), QVGA (160X120)
COLOR COLOR, B&W (Black and White)
COMPRESSION HIGH, LOW (more/less distortion)
F L A S H ENABLED, DISABLED
# OF PICTURES 1–9; 1–5 VGA (3)
For Future Use
PICTURE DELAY 0–480 MS (480)
USER MONITOR ENABLE, DISABLE
ZONE ASSIGNMENT 00-00-00-000 – Movement detection in any of the up-to-four specified
zones tri
