f) Speaker Module
The Speaker can be used to make a sound.
NOTE: As a default, the speaker is connected through pin P0 of the micro:bit, therefore it
is important to connect the speaker module to Connector A0.
Image 3.4f – Speaker Module
Module
Connect Type
Available Connectors
Speaker Module
Analog
A0
EXAMPLE:
Play a Sound Through the Speaker
The speaker will cycle through three sounds/beats.
