i) Switch Module
The switch module can used to switch between two options (ie. on/off).
Image 3.4i – Switch Module
Module
Connect Type
Available Connectors
Switch Module
Digital IO
D12, D13, D14, D15
Block API
Check the switch's status
Check whether the switch is open or closed.
Function
