User Manual V3.1
Element14 | element14.com/minode 20
While rotating the rotary dial, the LED screen will display a smiley face. When the dial is
stationary, no LEDs will be lit on screen.
e) Mini Fan Module
The mini fan module is designed to be used with the DC motor and Orbit Fan. The speed
of the motor can be controlled according to different situations.
Image 3.4e – Mini Fan Module with DC Motor and Orbit Fan
