ENCLOSING the FIREPLACE
Element4 Gas Fireplaces EuropeanHome.com
Set the receiver into the Wall
Access Door bracket as shown
and connect the AC adapter.
Wall Access Door with
gas control and receiver
mounted.
TEST FIRE
Prior to being placed into operation, the replace should be test-red in stages to ensure that all components are in good working
order. This replace has a 2
nd
thermocouple which senses the main burner ame. The system will turn itself o if the system does
not sense the 2
nd
thermocouple output within 20 seconds after the main valve opens.
Note that a single, long beep indicates that the 2
nd
thermocouple is still hot enough to produce electricity at the receiver which will
not allow the replace to start. Allow time for the 2
nd
thermocouple to cool down before attempting a start. The system is ready to
start when pressing the ON/OFF button produces a response from the valve.
1. Start the replace without the hearth panel out and with the front glass o. Ensure that the pilot ame both heats the
primary thermocouple and lights the main burner. For safety, a post-purge delay is built into the system. Subsequent start
attempts MUST NOT take place for at least thirty (30) seconds.
2. Start the replace with the hearth panel in place and with all of the glass panels xed correctly in place. Ensure that the
main burner ames engulf the 2
nd
thermocouple and the replace stays lit for at least 1 full minute. If the system turns itself
o after 20 seconds install the required media (next section) and return here. Installing the re media will help with the
ame around the 2
nd
thermocouple. Subsequent start attempts MUST NOT take place for at least ve (5) minutes.
3. Start the replace with the media installed. If the system turns itself o after 20 seconds, rearrange the media to produce
a good ame at the 2
nd
thermocouple. This step may have to be repeated several times before the media is in the best
place for consistent operation. A single, long beep indicates that the 2
nd
thermocouple is still too hot to start the ignition
sequence. Allow time for the 2
nd
thermocouple to cool down. Once the system stays lit for at least one full minute, turn
the replace o, x the glass panels in place and operate the replace for at least 45 minutes to ensure the system works
properly when heated.
