34
ENCLOSING the FIREPLACE
Element4 Gas Fireplaces EuropeanHome.com
Sky/Sky T
with End Wall Outlets
Sky/Sky T
with Outlet in Reveal
CONVECTION AIR OPENING
A convection air outlet is always required. The opening size of the convection air outlet varies by replace model. The CLEARANCES
section shows the minimum total area required for the various models in this manual. The convection air outlet may take many forms
and must always allow the free ow of warm air up through the chase and out into the room in which the replace is installed. Shown
here are a number of ways to design the convection air outlet into your project.
Convection Air Outlet Area by Model
Model
Square
Inches
Square
Centimeters
Sky 35 258
Sky T 70 516
