Element4 Sky - Page 33

33
ENCLOSING the FIREPLACE
Element4 Gas Fireplaces EuropeanHome.com
SKY/SKY T
Product Thickness
Skamol Skamotec® 225 Fireplace Building Board 1½”/38 mm
Promat PROMAFOUR® System ½”/12 mm, ⁄”/15 mm, ¾”/18 mm
James Hardie Building Products HardieBacker® 500 ½” Cement Board ½”/12 mm
James Hardie Building Products HardieBacker® ¼” Cement Board ¼”/6 mm
The nished wall(s) must be at least 1⁄”/28 mm thick or the replace trim will extend beyond the nished wall. The list below shows
the thickness of the approved wall products.
Your choice of wall material depends largely on the intended nish. For example, a thinner wall product and a layer of stone may be
thick enough to reach the trim edge. If a painted nish is desired then a wall at least 1⁄”/28 mm thick will suce.
Minimum Wall Thickness = 1⁄”/28 mm
Fireplace Trim
