ENCLOSING the FIREPLACE
Element4 Gas Fireplaces EuropeanHome.com
BUILDING THE ENCLOSURE
A safe installation of your Element4 replace requires that four things be clearly understood.
1. Most important, these replaces are NOT zero-clearance replaces. Unlike zero-clearance replaces, there is not a metal box
around the Element4 replaces. With no metal box there are no louvers to distract your view of the re. However, we want the
cooling advantage of a metal box so your site-built, non-combustible enclosure will substitute.
2. Your replace enclosure must be made to act the way a metal replace box acts - letting room air in below and warm
convection air out above. The framing cannot interfere with the air ow. The Room Air Inlet is part of the replace and cannot
be changed or adjusted. The convection air outlet is part of your enclosure design, is provided by you and MUST be included.
Note: The convection air outlet must be installed in the same room as the replace or a space which ALWAYS ows air into the room
in which the replace is installed. The ow of convection air must NOT be blocked.
3. Since these are not zero-clearance replaces, the clearances and dimensions listed in the CLEARANCES section MUST be
maintained. Only the non-combustible wall, the mounting brackets and the venting may touch the replace. As previously
stated, nothing may be built closer than 2”/50 mm to the non-glass sides.
4. The controls will be mounted to your enclosure and below the burner. The controls are at the end of a 50”/1270 mm line set
and are to be mounted to the Wall Access Door which is included. The controls must be located for ease of physical access
(gas line, maintenance, etc.) as well as wireless signal (remote control) access. See the LOCATING THE CONTROLS and the MOUNTING THE
CONTROLS sections.
The combination of multiple glass sides and no zero-clearance box makes for a non-typical enclosure project. It may seem
straightforward to build the ‘rough opening’, set the replace then attach the wall. However, for most projects, it will be easier to
rst set the replace in position then enclose it with Skamol Skamotec® or Promat PROMAFOUR® building board.
ONLY non-combustible framing can be used to enclose these replaces.
REDUCED CLEARANCE TO EXISTING COMBUSTIBLE WALLS
When retrotting the replace against an existing wall it is often desirable to reduce the distance between the replace and the
combustible wall. Normally, this distance is 11”/280 mm but it may be reduced by shielding the existing nished wall with a sheet of
non-combustible material as shown.
IN ALL CASES:
• A reduced clearance shield is ONLY ALLOWED ON A VERTICAL WALL; IT IS NOT ALLOWED TO BE USED ON OTHER SURFACES WITHIN
THE NON-COMBUSTIBLE ZONE.
• The non-combustible wall shield MUST extend more than 26”/660 mm above the top of the replace. The shield shall be placed
no closer than 1”/25 mm to the oor or any intersecting walls. Air MUST be allowed to continually circulate around all sides of the
wall shield.
• A 1”/25 mm air gap between the wall shield and the existing wall MUST be maintained.
• A 2”/50 mm air gap between the wall shield and the replace MUST be maintained.
