Product description
Stereo L/R (XLR) − Cn no. 11
Pin. # Function Type Note
1 Common Gnd //
2 Input L/R + Bal.
600Ω/10kΩ
3 Input L/R − Bal.
AES/EBU (XLR) − Cn no. 14
Pin. # Function Type Note
1 Common Gnd //
2 Input + Diff.
110Ω
3 Input − Diff.
MPX − Cn no. 13
Pin. # Function Type Note
1 Input Unbal.
600Ω/5kΩ
2 Common Gnd //
Aux1 + Aux2 − Cn no. 12, 10
Pin. # Function Type Note
1 Input Unbal.
10kΩ
2 Common Gnd //
MPX Monitor − Cn no. 15
Pin. # Function Type Note
1 Input Unbal.
10kΩ
2 Common Gnd //
RF Monitor − Cn no. 1
Pin. # Function Type Note
1 Output Unbal.
50Ω
2 Common Gnd //
AC Line Input and Grounding − Cn no. 22, 23
Pin. # Function AWG/sqmm Note
1 Phase 13/2.5 max
100−240Vac
2 Neutral 13/2.5 max
3 Gnd 13/2.5 max /
G Gnd 13/2.5 max M4
31
4.2.3 Stereo L/R − AES/EBU
4.2.4 Aux1 − Aux2 − MPX − MPX Monitor
4.2.5 RF Monitor
4.2.6 Line Input − Grounding
