66
6.3.2 Connecting to a Change Over/Audio Matrix
In N+1 systems, the apparatus may be a transmitter or the reserve (the exciter and
its connections aren’t shown).
Examples of connections between these devices are shown below.
Tx1 in a N+1 system
Reserve in a N+1
system
Reserve in a N+1
system with Audio
Matrix
Reserve in a N+1
system with double
Audio Matrix
