Elenos ETG5200 User Manual

17Product description
open
collector
23 Bad audio Signaling output
The pin must be po-
wered externally.
“Closed to ground”
status → Active alarm
open
collector
24 /FLT (reversed pola-
rity)
Signaling output
The pin must be po-
wered externally.
“Open” Status → Acti-
ve alarm
The operation can be
affected by the set-
tings of the machine
open
collector
25 Remote Signaling output
The pin must be po-
wered externally.
“Closed to ground”
status → Remote
signal active
2.1.7.1 Full scale values
The nominal full scale corresponds to +4 V, with over stroke of up to more than +4.5
(max +5 V).
ETG5000
Parameters Full scale Scale factor Resolution
Forward power 5000W 1250W * V Full scale/204
Reflected power 500W 125W * V
IPA (current amplifier) 200A 50A * V
VPA (voltage amplifier) 50V 12.5V * V
ETG3500
Parameters Full scale Scale factor Resolution
Forward power 3500W 875W * V Full scale/204
Reflected power 350W 87.5W * V
IPA (current amplifier) 150A 37.5A * V
VPA (voltage amplifier) 50V 12.5V * V
ETG2500
Parameters Full scale Scale factor Resolution
Forward power 2500W 625W * V Full scale/204
Reflected power 250W 62.5W * V
IPA (current amplifier) 150A 37.5A * V
VPA (voltage amplifier) 50V 12.5V * V
