5.1.3 Accessories
5.1.3.1 MW Z16
Mounting handle
The mounting angle will be mounted with two long screws (contained in the shipping) together with the rear-
panel of the unit. It is turn able and can put thus the Z16 in any slopes, in order to enable the user the
optimal reading. With the 2 boreholes shown in above diagram the unit can be fixed (for example on the
guidance carriage).
Technical Data
MW Z-16
2 x borehole
