7.4 Functions in Normal mode
7.4.1 Set datum value
F and Set 1x press together
With this key combination the actual value will be set to the reference value. (Only in the ABS-mode possible,
if no offset level is activated.) The reference value is entered in parameter P09.
7.3.2 Switching incremental / absolute
incr/abs 1x press
With this key the unit switch from absolute mode to incremental mode:
The display value is set to zero, and display the symbol "INC". Pressing the button again the display set again
into absolute mode and “abs” is shown again.
