- 13 -
5.2 Technical Data
Display Z16
LCD-Display
7 Decades (Digit height 11mm)
Status of Battery and Unit
Power supply 1 x Battery (1,5 V)
Consumption with encoder < 1 mA at 1,5 V
Operation temperature +5 ° up to + 50 ° C
Drive speed max. 2,5 m/sec
Housing Material: Metal, black
Housing dimensions W x H = 96 x 72 mm
Installation depth 40 mm (incl. cable)
Front panel outbreak W x H = 92 x 66 mm
Protection class IP 43 (installed)
Magnetic Sensor MS20.25
Sensor cable length 0,1 m up to max. 2,0 m (more on request)
Resolution 0,1mm
Protection class IP66 Zinc die cast
Operation temperature +5° up to + 50° C
min. Radius to bend min. 60 mm
Distance Sensor/Tape max. 1,0 mm (without cover tape „C“)
Magnetic Tape MB 20-25-10-1-R
Operation temperature 0° up to + 50°C
Accuracy at 20° C in mm +/- (0,025 + 0,02 x L) L = effective Measuring length in m
Length expansion coefficient
= 16 x 10-6 x 1/K
Radius to bend min. 150 mm
