- 16 -
7.2.5 Parameters
Parameter Description Default Parameters
P01: AB mm / inch Switching
A = 0: mm – Mode
A = 1: Inch – Mode (Resolution 0,001 Inch )
Counting direction:
B = 0: positive
B = 1: negative
01
P03: A Decimal point ( 0 ... 3 ) 1
P05: AB Key lock:
A: Button „ SET “ ( 0 = active / 1 = not active)
B: Button„ Incr / Abs „ ( 0 = active / 1 = not active)
00
P08: Multiplication factor (0,0001 ... 9,9999 ) 1,0000
P09: Reference value( -999999,9 ... + 999999,9 ) 0,0
P99: Displays the Firmware – Version X.XX
