1560 DIGITAL ISOLASJONSMÅLER MED KONTINUITET
Measure-
ment of
insulation
resistance
(50V)
0,01M~19,99M
20,0M~50,0M
0,01MΩ
0,1MΩ
0,01MΩ~50,0MΩ:
3%+5
25V
1.Short-circuit current less than
2mA
2.Range of measurement is
described below:50V: 0,01MΩ-
50,0MΩ, there will be buzzing
alarm output in case of less than
1MΩ; 100V:0,01MΩ- 100,0MΩ
there will be buzzing alarm
output in case of less than1MΩ;
250V: 0,01M-200,0MΩ, there
will be buzzing alarm output in
case of less than 4MΩ
500V: 0,01M-500MΩ, there will
be buzzing alarm output in case
of less than 4MΩ
500V: 0,01M-10,0MΩ, there
will be buzzing alarm output in
case of less than 4MΩ
(100V)
0,01M~19,99M
20,0M~100,0M
1MΩ
0,01GΩ
0,01MΩ~100,0MΩ:
3%+5
(250V)
0,01M~19,99M
20,0M~200,0M
0,01MΩ
0,1MΩ
0,01MΩ~200,0MΩ:
1,5%+5
(500V)
0,01M~19,99M
20,0M~199,9M
200M~500M
0,01MΩ
0,1MΩ
1MΩ
0,01MΩ~500,0MΩ:
1,5%+5
(1000V)
0,01M~19,99M
20,0M~199,9M
200M~2000M
2,0G Ω~20,0G
Ω
0,01MΩ
1MΩ
0,1GΩ
0,01MΩ~200,0MΩ:1,5%+5
200MΩ~2000MΩ:1,5%+5
2,0GΩ~10,0GΩ:10%+3
10,0GΩ~20,0GΩ:20%+10
Measure-
ment of low
resistance
20,00K Ω
0,01Ω ±1,5%+3
2V
AC/DC
Open-circuit voltage is about
5,0V; Short- circuit current is
higher than 200mA.
Voltage
measure-
ment
600,0V AC 0,1V ±(2%+3) 600V AC 1.Input impedance: 10MΩ
2.Minimum measured: 0,1V
3.Frequency: DC/50Hz~400Hz
600,0V DC 0,1V ±(2%+3) 600V DC
