1560 DIGITAL ISOLASJONSMÅLER MED KONTINUITET 31
2. Electrical specifications
- Limit of error: ± (a% reading + word count),with calibrating interval being one year;
- Environmental temperature: 23±5°C ;
- Environmental humidity: 45~75%RH;
- Temperature coefficient: 0.1* (accuracy) /°C:
3. Technical indicator (see figure 2)
Output
voltage
50V Stepping10%
50%~120% 0%~+10% 250V
50V Output range : 25V~60V
100V Stepping10%
100V Output range : 50V~120V
250V Stepping 10%
250V Output range: 125V~300V
500V Stepping10%
500V Output range : 250V~600V
1000V Stepping 10%
1000V Output range : 500V~1200V
Rated
current
1mA
0%~+10% 250V
50V Load resistance 50k Ω
1mA
100V Load resistance 100k Ω
1mA
250V Load resistance 250k Ω
1mA
500V Load resistance 500k Ω
1mA
1000V Load resistance 1M Ω
Short-
circuit current
Less than 2mA
High voltage output terminal is short
circuited with EARTH terminal
GB
