COPY CARD
UL 2
Up load. Programming parameter transfer from instrument to Copy Card.
Fr 2
Format. Erasing all data in the copy card.
(!) WARNING!
• If one or more of these parameters highlighted with (!) are modied, the controller must be switched off and
switched on again to ensure correct operation.
• Parameter H25 is present only in model with buzzer on board.
SUPERVISION
The device can be connected to:
• telecontrol system TelevisSystem (°)
• ParamManager fast parameter setting software
• DeviceManager fast parameter setting software (only parameter table)
The connection can be made via TTL serial port.
For connection to RS-485 bus use TTL/RS485 interface BusAdapter 150.
For connection to PC should be used:
• for TelevisSystem: PCInterface 1110/1120 with Televis licence;
• for ParamManager: PCInterface 2150/2250 with ParamManager licence;
(°) To congure the instrument for this purpose, use parameters “dEA” and “FAA” in the “Programming” menu.
