ELECTRICAL WIRING
Attention! Never work on electrical connections when the machine is switched on.
The device is equipped with screw or removable terminals for connecting electric cables with a diameter of 2.5mm
2
(one wire per terminal for power connections).
For the capacity of the terminals, see the label on the instrument.
Do not exceed the maximum current allowed; in case of higher loads, use an appropriate contactor.
Make sure the power supply voltage complies with the one required by the instrument.
Probes have no connection polarity and can be extended using a regular bipolar cable (note that the extension of
the probes affects the EMC electromagnetic compatibility of the instrument: pay extreme attention to wiring).
Probe cables, power supply cables and the TTL serial cables should be distant from power cables.
RESPONSIBILITY AND RESIDUAL RISKS
ELIWELL CONTROLS SRL shall not be liable for any damages deriving from:
- installation/use other than that prescribed and, in particular, that which does not comply with safety standards
anticipated by regulations and/or those given herein;
- use on boards which do not guarantee adequate protection against electric shock, water or dust under the
conditions of assembly applied;
- use on boards which allow access to dangerous parts without the use of tools;
- tampering with and/or alteration of the products;
- installation/use on boards that do not comply with the standards and regulations in force.
DISCLAIMER
This manual and its contents remain the sole property of ELIWELL CONTROLS SRL, and shall not be reproduced or
distributed without authorization by ELIWELL CONTROLS SRL.
Although great care has been exercised in the preparation of this document, ELIWELL CONTROLS SRL, its employees
or its vendors, cannot accept any liability whatsoever connected with its use.
The same applies to any person or company involved in preparing and editing this document.
ELIWELL CONTROLS SRL reserves the right to make any changes or improvements without prior notice.
