EWPlus 978 - EWKPlus 978
10/12
Param. DESCRIPTION RANGE M.U. AP1 AP2 AP3
Fon
Fans ON time in duty cycle. Fans used in duty cycle mode;
valid when FCO = dc and H42=1 (probe Pb2 present)
0 ... 250 min 0 0 0
FoF
Fans OFF time in duty cycle. Fans used in duty cycle mode;
valid when FCO = dc and H42=1 (probe Pb2 present)
0 ... 250 min 0 0 0
ALARMS (folder AL)
Att
HAL and LAL parameters mode, i.e. the absolute temperature value or differential in relation to the
setpoint. 0 = absolute value; 1 = relative value.
NOTE: In case of relative values (par. Att=1), the HAL parameter should be set to positive
values, while the LAL parameter should be set to negative values (-LAL).
0/1 num 0 0 1
AFd Alarms activation differential. 1.0 ... 50.0 °C/°F 2.0 2.0 1.0
HAL (!)
Maximum temperature alarm. Temperature value (intended either as distance from setpoint or as an absolute
value based on Att) which, if exceeded in an upward direction, triggers the activation of the alarm signal.
See “Max/Min temperature alarms”.
LAL to 320 °C/°F 50.0 50.0 8.0
LAL (!)
Minimum temperature alarm. Temperature value (intended as distance from setpoint or as an absolute
value based on Att) which, when exceeded downwards, triggers the activation of the alarm signal.
See “Max/Min temperature alarms”.
-67.0 to HAL °C/°F -50.0 -50.0 -2.0
PAO (!)
Alarm override time after device is switched on following a power failure.
This parameter refers to high/low temperature alarms only.
0 ... 10 hours 1 1 1
dAO Temperature alarm exclusion time after defrost. 0 ... 999 min 60 60 60
OAO Alarm signal delay (low and high temperature) after the deactivation of the digital input (port closed). 0 ... 10 hours 0 0 0
tdO Delay in door open alarm activation. 0 ... 250 min 0 0 0
tAO
Time delay for temperature alarm indication.
This parameter refers to high/low temperature alarms only.
0 ... 250 min 90 90 120
dAt Alarm signalling end of defrost due to timeout. n (0) = alarm not activated; y (1) = alarm activated. n/y flag n n n
rLO Regulators locked by external alarm. n (0) = does not lock; y (1) = locks. n/y flag n n n
SA3 Alarm setpoint for probe Pb3. -67.0 ... 320 °C/°F 50.0 50.0 50.0
dA3 Probe Pb3 alarm activation differential. 1.0 ... 50.0 °C/°F 1.0 1.0 2.0
LIGHTS AND DIGITAL INPUTS (folder Lit)
dOd
Enable utility switch-off on activation of door switch.
0 = disabled 1 = disables fans
2 = disables the compressor; 3 = disables fans and compressor
0/1/2/3 num 0 0 0
dAd Digital input activation delay. 0 ... 255 min 0 0 0
dCO Delay in deactivating compressor after door opened 0 ... 255 min 0 0 0
dCd Delay in activating fans after door closed 0 ... 250 secs 0 0 0
PRESSURE SWITCH (folder PrE)
PEn Number of errors allowed per pressure switch input. 0 = disabled 0 ... 15 num 0 0 0
PEI Pressure switch error count interval. 1 ... 99 min 1 1 1
PEt Delay in activating compressor after pressure switch deactivation 0 ... 255 min 0 0 0
DEEP COOLING (folder dEC)
dCS Deep cooling setpoint -67.0 ... 320 °C/°F -30.0 -30.0 -30.0
tdC Deep cooling duration 0 ... 255 min 60 60 60
dcc Defrost delay after deep cooling 0 ... 255 min 0 0 0
Sid Threshold for start of deep cooling -67.0 ... 320 °C/°F 10.0 10.0 10.0
toS Deep cooling activation time 0 ... 255 min 30 30 30
ENERGY SAVING (folder EnS)
ESt
Energy Saving mode:
0= disabled; 1= Offset on setpoint; 2= Offset on differential;
3= offset on setpoint and differential; 4= not used; 5= not used; 6= not used
0 ... 6 num 0 0 0
OSP Offset setpoint -30.0 ... 30.0 °C/°F 0.0 0.0 0.0
OdF Differential offset 0.0 ... 30.0 °C/°F 0.0 0.0 0.0
COMMUNICATION (folder Add)
PtS Select protocol. t (0) = Televis; d (1) = ModBus. t/d flag d
Parameters
not present
in vectors
dEA Device address: indicates the device address to the management protocol. 0 ... 14 num 1
FAA Family address: indicates the device family to the management protocol. 0 ... 14 num 0
Pty Sets Modbus parity bit. n (0) = none; E (1) = equal; o (2) = unequal. (only if PtS=d) n/E/o num n
StP Sets Modbus Stop bit. 1b/2b flag 2b
StO Serial 1 timeout. 0 ... 255 secs 0
DISPLAY (folder diS)
LOC
LOCk. Setpoint edit lock. You will still be able to open parameter programming and alter parameters,
including the state of this parameter if you need to unlock the keyboard for example.
n (0) = no; y (1)= yes.
n/y flag n n n
PS1 PAssword 1. When enabled (PS1 ≠ 0), this password provides access to level1 parameters (User). 0 ... 250 num 10 10 10
PS2 PAssword 2. When enabled (PS2 ≠ 0), this password provides access to level2 parameters (Installer). 0 ... 250 num 10 10 10
ndt Display with decimal point. n (0) = no (integers only); y (1) = yes (display with decimal point). n/y flag y y y
CA1
Calibration 1. Positive or negative temperature value added to the value read by Pb1.
This sum is used both for the temperature displayed and for regulation.
-12.0...12.0 °C/°F 2.0 4.0 0.0
CA2
Calibration 2. Positive or negative temperature value added to the value read by Pb2.
This sum is used both for the temperature displayed and for regulation.
-12.0...12.0 °C/°F 0.0 0.0 0.0
CA3
Calibration 3. Positive or negative temperature value added to the value read by Pb3.
This sum is used both for the temperature displayed and for regulation.
-12.0...12.0 °C/°F 0.0 0.0 0.0
