Eliwell IDplus 902 User Manual

PAR. DESCRIPTION RANGE App1 App2 App3 App4 M.U.
H50
Enable HACCP and alarm relay functions. 0 = HACCP alarms NOT enabled;
1 = HACCP alarms enabled and alarm relay NOT enabled;
2 = HACCP alarms enabled and alarm relay enabled.
0/1/2 0 0 0 0 num
H51 HACCP alarm exclusion time. 0 ... 250 0 0 0 0 min
CONFIGURATION (“CnF” folder)
H00 Probe type selection. 0 = PTC; 1 = NTC; 2 = PT1000. 0/1/2
1 1 1 1
num
H11
Configuration of digital input 1/polarity. 0 = disabled; ±1 = defrost; ±2 = economy
Setpoint; ±3 = not used; ±4= door switch; ±5 = external alarm; ±6= Standby;
±7= pressure switch; ±8= Deep Cooling; ±9= disable HACCP alarm logging.
NOTE: • the “+” sign indicates that the input is active if the contact is closed.
• the “-” sign indicates that the input is active if the contact is open.
-9 ... +9 2 2 0 0 num
H21
(IDPlus 961 only). Configurability of digital output 1 (
).
0= disabled; 1= compressor; 2= defrost; 3= fans; 4= alarm; 5= AUX; 6= Standby.
0 ... 6 1 1 1 1 num
H22
(IDPlus 902 only). Configurability of digital output 1 (
). Same as H21.
0 ... 6 1 1 1 1 num
H31
Configurability of UP key.
0 = disabled; 1 = defrost; 2 = not used; 3 = economy Setpoint; 4 = Standby;
5 = reset HACCP alarms; 6 = disable HACCP alarms; 7 = Deep Cooling.
0 ... 7 1 0 0 1 num
H32 Configurability of DOWN key. Same as H31. 0 ... 7 0 0 0 0 num
H43 Probe Pb3 present. n = not present; y = present. n/y n n n y flag
reL Device version. Read-only parameter. / / / / / /
tAb tAble of parameters. Reserved: read-only parameter. / / / / / /
COPY CARD (“FPr” folder)
UL Programming parameter transfer from instrument to Copy Card. / /
/ / /
/
Fr
Format Copy Card. Erase all data contained in the Copy Card.
NOTE: if parameter “Fr” is used, the data entered will be permanently lost.
This operation cannot be cancelled.
/ / / / / /
FUNCTIONS (“FnC” folder)
rAP Reset pressure switch alarms / / / / / /
rES Reset HACCP alarms / / / / / /
NOTE
: If one or more parameters marked with (!) are modified, the controller MUST be switched off and then switched on again to ensure correct operation.
