Password “PA1”: used to access User parameters. The password is not enabled by default (PS1=0).
To enable it (PS1≠0): press and hold
set
for longer than 5 seconds, scroll through the parameters using and
until you see the label PS1, press
set
to display the value, modify it using and , then save it by pressing
set
or . If enabled, it will be required in order to access the User parameters.
Password “PA2”: used to access Installer parameters. The password is enabled by default (PS2=15).
To modify it (PS2≠15): press
set
and hold for longer than 5 seconds, scroll through the parameters using and
until you see the label PA2, press
set
, set the value to “15” using and , then confirm using
set
.
Scroll through the folders until you find the label diS and press
set
to enter. Scroll through the parameters using
and until you see the label PS2, press
set
to display the value, modify it using and , then save it by
pressing
set
or . The visibility of “PA2” is as follows:
1) PA1 and PA2 ≠ 0: Press and hold
set
for longer than 5 seconds to display “PA1” and “PA2”. It will then be
possible to decide whether to access the User (PA1) or the Installer (PA2) parameters.
2) Otherwise: The password “PA2” is amongst the level1 parameters. If enabled, it will be required when
accessing the Installer parameters; to enter it, proceed as instructed for password “PA1”.
If the password entered is incorrect, the label PA1/PA2 will be displayed again and the procedure will need to be
repeated.
PASSWORD
The Copy Card is connected to the serial port (TTL) and allows rapid programming of the instrument parameters.
Access Installer parameters by entering “PA2”, scroll through the folders using
and until folder FPr appears.
Select it using
set
, scroll through the parameters using and , then select the function using
set
(e.g. UL).
• Upload (UL): Select UL and press
set
. This function uploads the programming parameters from the instrument to
the card. If the procedure is a success, “y”, will appear on the display, otherwise “n” will appear.
• Format (Fr): This command is used to format the copy card, (recommended when using the card for the first time).
Important: the Fr parameter deletes all data present. This operation cannot be cancelled.
• Download: Connect the Copy Card when the instrument is switched off. At power-on, data is downloaded from the
copy card to the instrument automatically. At the end of the lamp test, the display will show “dLy” if the
operation was successful and “dLn” if not.
NOTE: After downloading, the instrument works with the settings of the new map just downloaded.
USING THE COPY CARD
