PAR. DESCRIPTION RANGE App1 App2 App3 App4 M.U.
SEt Temperature control SEtpoint. LSE ... HSE 0,0 0,0 0,0 -2,0 °C/°F
COMPRESSOR (“CP” folder)
diF diFferential. Compressor relay activation differential. 0,1...30,0
2,0 2,0 2,0 0,1
°C/°F
HSE Higher SEt. Maximum value that can be assigned to the Setpoint. LSE...302 99,0 140 140 5,0 °C/°F
LSE Lower SEt. Minimum value that can be assigned to the Setpoint. -58.0...HSE -50,0 -55,0 -55,0 -10,0 °C/°F
OSP
Temperature value to be added to the Setpoint if reduced set enabled
(Economy function).
-30,0...30,0 3,0 3,0 0,0 0,0 °C/°F
Hc Control mode. “H” = Hot, “C” = Cold. C/H C C H C flag
Ont
Controller on time for faulty probe.
if Ont = 1 and OFt = 0, the compressor remains on;
if Ont =1 and OFt>0 it runs in duty cycle mode.
0 ... 250 0 0 0 0 min
OFt
Controller off time for faulty probe.
if OFt = 1 and Ont = 0, the controller remains off;
if OFt = 1 and Ont > 0, it operates in duty cycle mode.
0 ... 250 1 1 1 1 min
dOn Compressor relay activation delay after request. 0 ... 250 0 0 0 0 secs
dOF Delay after switching off and subsequent activation. 0 ... 250 0 0 0 0 min
dbi Delay between two consecutive compressor activations. 0 ... 250 0 0 0 0 min
OdO
(!)
Delay in activating outputs after the instrument is switched on or after a power failure.
0 = not active.
0 ... 250 0 0 0 0 min
dcS Deep Cooling cycle Setpoint. -58,0...302 0,0 0,0 0,0 0,0 °C/°F
tdc Deep Cooling cycle duration. 0 ... 255 0 0 0 0 min*10
dcc Defrost activation delay after a Deep Cooling cycle. 0 ... 255 0 0 0 0 min
DEFROST (“dEF” folder)
dit Interval between the start of two consecutive defrost cycles. 0 ... 250 6 0 0 8 hours
dCt
Selection of count mode for the defrost interval.
0 = compressor running time;
1 = appliance running time;
2 = A defrost cycle is run at each compressor stop.
0/1/2 1 1 1 1 num
TABLE OF INSTALLER MENU PARAMETERS (IDPLUS 902/961)
