Output Characteristics
Digital outputs: IDPlus 902: 1 OUT1 relay: N.O. 8(4)A - N.C. 6(3)A max 250Va
IDPlus 961: 1 Compressor relay: UL60730 (A) 2Hp (12FLA - 72LRA) max 240Va
IDPlus 971: 1 Defrost relay: N.O. 8(4)A - N.C. 6(3)A max 250Va
1 Compressor relay: UL60730 (A) 2Hp (12FLA - 72LRA) max 240Va or
IDPlus 974: 1 Defrost relay: N.O. 8(4)A - N.C. 6(3)A max 250Va
1 Compressor relay: UL60730 (A) 2Hp (12FLA - 72LRA) max 240Va or
1 Fans relay: 5(2)A max 250Va
Mechanical Characteristics
Casing: PC+ABS UL94 V-0 resin casing, polycarbonate window, thermoplastic resin keys
Dimensions: front panel 74x32 mm, depth 59 mm (without terminals)
Terminals: screw/disconnectable terminals for cables with a diameter of 2.5mm
2
Connectors: TTL for connection of Copy Card + D.I.2 (IDPlus 971/974 models only)
Humidity: Use / Storage: 10…90% RH (non-condensing)
Regulations
Electromagnetic compatibility: The device conforms to Directive 2004/108/EC
Safety: The device conforms to Directive 2006/95/EC
Food Safety: The device complies with standard EN 13485 as follows:
- suitable for storage
- application: air
- climate range A
- measurement class 1 in the range from -25°C to 15°C (*)
(* exclusively using Eliwell probes)
NOTE: The technical specifications given in this document regarding measurement (range, accuracy, resolution,
etc.) refer to the instrument and not to any accessories provided, such as the probes. This means, for example, that
the error introduced by the probe must be added to the typical error of the instrument.
