EZWSR*1C, *2C LZWSR*1C, *2C
1000001734 (Rev. K - 04/18)
PLUMBING DIAGRAMS
VERSATILE BI-LEVEL
Barb capped
when not used
Barb capped
when not used
Barb capped
when not used
Barb capped
when not used
Bottle Filler
Drain
Bottle Filler
Drain
Bottle Filler
Drain
Bottle Filler
Drain
