Ellard Spider - Component Positions - Bi - Partition

12
Components' position (bipartition)
L
L+10
208
165
70
418
M
u
c
120
W
Header profile length
Motor dimension min
Deflection unit
Trolley distance
L=2W+20
M= W-210
u= W-190
c=W/2-184
Header profile length
L=
Opening travel W=
Motor dimension min
.580 M=
Deflection unit min.600 u=
Belt length f=
Trolley distance c=
1600 1800 2000 2200 2400 2600 3000 3200 3400 3800 4200 4600 5200 6200
790 580 600
2530
211
890 680 700
2930
261
800 990 780
3330
311
1090
880 900
3730
361
1190
980
1000 4130
411
1100 1290 1080 4530
461
1490 1280 1300 5330
561
1590 1380 1400 5730
611
1690 1480 1500 6130
661
1890 1680 1700 6930
761
2090 1880 1900 7730
861
2290 2080 2100 8530
961
2590 2380 2400 9730 1111
3090 2880 2900
11730
1361
Componen Positions for Bi-patition
12
