Ellard Spider - Sectional View of Track and Cover

Sectional view of track and cover
Sectional view
Caution: This view is not in a scale of 1:1.
4
80
175
114.7
15-30 Adjustable
5mm (nominal ref) gap between
bottom of door and
floor guide
h
20mm (nominal ref)
'h' = door height
Sectional View of Track and Cover
4
