Safety Precautions
The contents and categories a user must abide by are presented and described by the following
graphic expressions.
Warning
Warning
Misuse may cause injury even death to the operator.
Caution
Misuse may cause injury or physical loss to the operator.
Prohibited actions.
Compulsory actions.
Installation and adjustment must be carried out according to the Installation Manual.
Failure to observe the correct
installation and adjustment
process could lead to
electric shocks or components becoming loose.
To reduce the risk of injury, no unauthorized personel must
pass through the
automatic door to enter the work site and alternative access should br sought.
No modification the components must be carried out.
Never use a power supply beyond the stipulated voltage or frequency stated in this
manual.
Opening
sensor
s
should be set and adjusted
so
that the opening area of the door
will fall into the range of detection without any blind spots.
Failure to give propper adjustment could cause injury to personnel.
Detection range of photocell
Safety Precautions
1
15cm and more 15cm and more 15cm and more 15cm and more
1m and more
1m and more1m and more
1m and more
12cm and more 12cm and more
12cm and more
12cm and more
Door leaf
Door leaf
detection range of the sensor
detection range of the sensor
detection range of the sensor
detection range of the sensor
less than the size of a passer-by
Side screen safety sensors should be set and adjusted to give protection at the
outer most travel points of the door.
Failure to give propper adjustment could cause injury to personnel.
