Ellard Spider - Lock and Release (Optional)

15
Lock and release (Optional)
Stop plate
Interior manual release
5-10mm
Installaon of Electric lock
1. Install the lock onto the rail according to picture
2. Install the stop plate onto the hanger
to be locked）
3. Fully close door, move the lock to the posion according to the picture.
The distance between lock plunger and stop plate should be 5-10mm
Close direcon
Lock
Lock
Stop plate
Manual release
(interior)
Interior and Outdoor manual
release Electric lock
Outdoor manual
release(oponal)
Rope pipe
Wirerope 2pcs
Rope pipe
Refer to m
anual
prior to
applicaon,
1. Check component according to manual
2. Check the lock working
condion and refer to circuit diagram before installing to door system
Operaonal principle: Power on -release Power off -lock
Working Voltage:
12V
dc
Main components : 1. Lock, 2.Stop plate, 3. Interior manual release, 4.Outdoor manual release (oponal)
I
nterior Manual release Electric LOCK
Lock and Release (Optional)
15
