30
If the lower looper thread breaks while sewing,
cut and remove needle threads from needle
eyes. Rethread lower looper. Rethread needle
eyes. Needles must be threaded after the lower
looper.
Turn the flywheel until the lower looper is in its
far right position. Thread the looper eye (A) from
front to back. Position thread into V cutout (B)
on threader.
Firmly hold thread tail with right hand and pull
threader lever (C) up into place (D).
Place thread under presser foot.
2
4
3
2 2
3
4
2
3
4 4
3
2
D
С
A
B
Lower Looper Automatic Threader
2. Lower Looper
(Green Threading Route)
Insert thread between green tension discs.
Pull thread down inside channel. Pass thread
through three green marked thread guides.
When threading the antenna guide, bring the
thread up from back to front.
Bring thread down to thread guide on top of
machine; slip thread under hook from right to
left. Go under guide, up over and around the
pre-tension disc to make an "S" curve.
To Next Page
