The upper (b) and lower (c) looper threads should
lock together on the rolled fabric edge. Adjust the
same as Overlock 3. See pages 50-52.
The fabric weight and fiber content may require
the SL (stitch length) to be adjusted. Stitch length
may be set from 1 to 4 (the higher the number,
the longer the length). Set a shorter stitch length
for lightweight or sheer fabrics. Set a longer stitch
length for heavyweight or bulky fabrics.
Rolled Edges
54
Stitch Length
c
b
a
c
b
a
Narrow Hem 3
Rolled Hem 3
The upper (b) and lower (c) looper threads should
lock together with the needle thread (a) on the
underside of the rolled fabric edge. If upper
looper thread (b) is not rolling to the underside,
loosen upper looper thread tension (yellow) and
tighten lower looper thread tension (green).
3
2
N
