n
Place the bobbin on the bobbin winder spindle
and push it to the right. The LED readout will
display “SP.”
o
Holding the free end of the thread, press the foot
control. Stop the machine when it has made a
few turns and cut the thread tail close to the
hole in the bobbin. Press the foot control again.
When the bobbin is fully wound, it will stop auto
matically.
p
Move the spindle to the left to return the bobbin
winder to its original position. Cut the thread as
shown.
Additional Spool Pin
The additional spool pin can be used to wind an ex-
tra bobbin without unthreading the machine.
PROCEDURE:
Insert the spool stand
k
and the ad-
ditional spool pin
l
in the hole
j
. Place the felt
m
and spool
n
on the pin with the thread coming off
the spool as shown.
17
5
6
7
5
4
3
2
1
