Winding a Bobbin
To remove bobbin, slide bobbin cover plate release
button to the right and lift away the bobbin cover
plate.
Lift out the bobbin.
•
Lift up the spool pin. Place the spool of thread on
the spool pin with the thread coming off the spool
as shown. Attach the spool holder and press it
firmly against the spool of thread.
NOTE:
Spool holder needs to be changed according
to the type of thread spool
A. Large spool
B. Small spool
k
Pull the thread towards the thread guides, under
the hook and wrap it around the guide as shown.
l
Pull the thread back around the bobbin winder
thread guide.
m
Pass the thread through the hole in the bobbin
from inside to the outside.
16
A
B
1
2
3
4
