ELNA eXperience 520 - SERVICE ACCESS (1) FACE COVER; Face Cover Removal; Face Cover Installation

4
MODEL 520
Cap
SERVICE ACCESS (1)
FACE COVER
TO REMOVE:
1. Remove the cap.
2. Remove the setscrew (A) and remove the face cover.
TO INSTALL:
3. Insert the three ribs and the hook on the face cover into the rear cover.
Tighten the setscrew (A) and attach the cap.
Ribs
Hook
Setscrew (A)
Face cover
